The Lab Gruppen C 16:4 is a rugged 2U, four‑channel installation amplifier delivering a total of 1600 W for both low‑impedance and 70/100 V distributed systems. Each channel offers an individually configurable Voltage Peak Limiter (VPL), allowing precise matching to the connected load, from single low‑Z loudspeakers to multi‑zone constant‑voltage lines. Adjustable input gain helps maximise headroom, while NomadLink connectivity enables integration into supervised systems for remote power, mute and status monitoring via DeviceControl.
Engineered for clean, consistent performance, the C 16:4 achieves THD below 0.1% (20 Hz–20 kHz at 1 W), a >112 dBA signal‑to‑noise ratio and >70 dB channel separation at 1 kHz. Frequency response spans 6.8 Hz to 34 kHz (±3 dB). Power delivery is rated at 400 W per channel into 8 or 16 ohms, 300 W into 4 ohms, and 400 W per channel for 70 V/100 V operation, with all channels driven. Built for dependable service in demanding installs, it is an excellent choice for theatres, conference venues, education spaces and houses of worship where reliability, control and audio quality are essential.
Includes
- Lab Gruppen C 16:4 4‑Channel Amplifier – 1600 W, NomadLink
