The Bose ShowMatch SM10 is a compact, high-output DeltaQ line array module built for exceptional vocal clarity and consistent audience coverage. Its 10° nominal vertical pattern combines with field-changeable waveguides to provide 70° or 100° horizontal dispersion; a single panel can be swapped to create asymmetrical patterns where needed. The 2-way design runs on two amplifier channels with DSP and delivers full-range performance from 59 Hz to 18 kHz with peak array output up to 145 dB SPL.
Four EMB2S compression drivers supply ample high-frequency headroom, while dual 8-inch neodymium woofers produce tight, controlled low-mid impact. Touring-friendly hardware includes 3-point quick-pin rigging with a 10:1 safety factor for up to 24 full-range modules, plus removable side rigging guards and handles for protection and easier handling. DeltaQ directivity focuses energy where it’s needed, enabling fewer modules to cover large vertical angles for more consistent results, reduced weight and lower system cost.
Ideal for touring productions, theatres, houses of worship and corporate AV, the SM10 provides scalable, precise coverage from small venues to large spaces.
Includes
- Bose ShowMatch SM10 DeltaQ Line Array Speaker – 10° vertical
