The NEXO NXAMP4X1 MK2 is a four-channel system amplifier that unites high-headroom Class D power with advanced loudspeaker processing for modern touring and install workflows. It delivers up to 4 x 1900 W at 4Ω (4 x 1200 W at 8Ω, 4 x 2500 W at 2Ω) with the option to bridge each channel pair for 2 x 5000 W at 4Ω or 2 x 3800 W at 8Ω, giving excellent flexibility from fills to main systems. A maximum output of 140 V per channel ensures strong voltage drive for demanding loudspeakers.
Audio quality is assured via 32-bit/96 kHz conversion and triple 64-bit multicore DSP, providing precise processing, around 550 μs latency and a smooth, musical ±1 dB response from 10 Hz to 20 kHz. Integration is streamlined with remote control/monitoring and an expansion slot supporting AES/EBU, EtherSound, Dante or AES67 for networked audio. With 20 kΩ input impedance, +16 dBu max input, and efficient power consumption (10 W standby, 200 W at rest), it’s engineered for reliability and performance.
Ideal for touring inventories, theatres, live venues, corporate AV and houses of worship.
Includes
- NEXO NXAMP4X1 MK2 Processor Amplifier 4x1900W DSP - Syste...
