The NEXO GEO S1230 is a compact 2‑way line array module engineered for scalable professional sound reinforcement. A 12‑inch neodymium LF driver pairs with a 1.4‑inch HF driver, coupled via NEXO’s HRW waveguide and DPD technology to deliver a coherent wavefront with excellent clarity and precise directivity. Its tight 30° vertical pattern and selectable 80°/120° horizontal dispersion in the non‑coupling plane ensure consistent coverage and intelligibility when arrayed. With frequency response from 53 Hz to 19 kHz (±3 dB), nominal sensitivity of 103 dB and peak output up to 131–133 dB when correctly powered, the S1230 offers impressive performance relative to its size. Built from robust Baltic birch, the enclosure integrates a quick, angle‑selectable rigging system for fast, secure deployment, and features Speakon connectivity. Flexible operation is supported with passive or active crossover at 1.1 kHz, and system design is streamlined via NEXO’s NS‑1 software. Ideal for touring rigs, theatres, houses of worship and corporate events, the GEO S1230 excels in flown arrays and fixed installs where controlled coverage and high output are essential.
Includes
- NEXO GEO S1230 Line Array Loudspeaker – 12-inch Module
STAGE4.1.100.000
