The PL-Audio B215 DSP is a high-output subwoofer built for serious low-frequency reinforcement in touring and installation. Delivering 1400 W RMS (2800 W programme) and capable of sound pressure levels beyond 137 dB, it provides tight, authoritative bass across a 40–165 Hz operating range. A 4‑ohm load makes amplifier pairing straightforward, while the Speakon assignment of 2+/2‑ for the sub with 1+/1‑ passed to the tops ensures clean, simple cabling in bi-amped systems. The DSP platform optimises response and offers protection, supporting consistent performance night after night. An active variant adds a 3‑channel Class D amplifier rated at 1 x 2500 W for the sub plus 2 x 800 W to power compatible tops, streamlining setup and reducing outboard requirements. Touring-friendly dimensions of 590 x 810 x 735 mm (with castors) and a robust build support dependable deployment, with weights of 57.0 kg (passive) and 61 kg (active). Ideal for live venues, mobile PA, clubs and corporate events where punch, headroom and tidy system wiring are essential.
Includes
- PL-Audio B215 DSP Subwoofer – 1400 W RMS, 40–165 Hz
STAGE22.2.100.100
