The NovaStar VX4S is a robust LED video wall controller with an integrated high‑performance scaler designed for quick setup and dependable show control. It offers versatile I/O including HDMI, DVI, DisplayPort, SDI, two VGA and two CVBS inputs, plus DVI and SDI loop outputs for clean pass‑through. A preview monitor can be connected via DVI or VGA to streamline cueing and confidence monitoring. Configure straightforward LED walls directly from the front panel without a PC, or use NovaStar software for advanced mapping and calibration. The VX4S drives up to 2.3 million pixels with a maximum width of 3840 pixels and provides four RJ45 output ports for reliable cabinet distribution. Housed in a rugged 1U, 19‑inch chassis with auto‑ranging 100–240 V power and low 16 W consumption, it suits touring racks and fixed installs alike. Dimensions: 483 x 275 x 45 mm; weight: 2.55 kg. Ideal for corporate events, live production, and installations needing solid LED processing and scaling.
Includes
- NovaStar VX4S LED Video Wall Controller & Scaler
STAGE22.1.100.399
