The Lab Gruppen FP 10000Q is a touring-grade, 4-channel power amplifier delivering a massive 10,000 W total output. Capable of up to 2,500 W per channel into 2 ohms, it provides the headroom and reliability demanded by professional sound reinforcement. Its proven Class-TD topology combines the sonic purity of Class A/B with the efficiency of Class D, while the regulated switch-mode power supply (R.SMPS) maintains consistent performance under challenging mains conditions. NomadLink networking with DeviceControl software enables real-time monitoring and control across large amplifier racks. Flexible configuration is assured with selectable gain, scalable Voltage Peak Limiter (VPL) and bridge-mode operation to match a wide range of loudspeakers. Robust thermal management via the Intercooler copper cooling system and comprehensive protection for current, voltage, DC, temperature, short circuit and open load safeguard both the amplifier and connected transducers. Connectivity includes four balanced XLR inputs and four Neutrik speakON outputs, all within a rugged 2U rackmount chassis with removable dust filters. Ideal for touring racks driving line arrays, subs and full-range systems in high-demand live sound applications.
Includes
- Lab Gruppen FP 10000Q FP 10000Q
