The Infiled M16 LED Video system delivers a robust 49.16 m² display solution built for demanding outdoor and indoor applications. Supplied as 122 x 640 × 640 mm IP65-rated panels with 16 mm pixel pitch (40 × 40 pixels per panel) and 38% transparency, it offers punchy output at over 5,000 nits for excellent visibility in direct sunlight, while maintaining quality at low brightness for indoor use. The package includes comprehensive rigging, control and cabling, plus generous spares, enabling fast deployment and reliable operation across single large walls or multiple independent screens.
This complete system is engineered for straightforward installation with LINSN control, dedicated rigging bars and flightcase logistics. It’s an ideal choice for clubs, stages, halls and open-air events requiring resilient performance and easy servicing, supported by a wide selection of spare LED tiles and hardware.
Use it for festival main stages, stadium signage, large-format outdoor branding, or modular creative video canvases where durability, brightness and flexible configurations are essential.
Includes
- 122 x 640 × 640 mm LED video panels (includes 2 spare frames)
- 3 flight cases for 24 panels each
- 3 flight cases for 16 panels each
- 6 x 1.28 m rigging bars
- 2 x 0.64 m rigging bars
- Controller
- Power interconnect cables
- Data interconnect cables
- Power inlet cables
- CAT lead set for up to 3 independent screens
- Spare LED tiles 640 × 160 (approx. 30)
- Spare LED strips and single LEDs
- Spare horizontal connector pieces
- Spare case castors and catches
