The Datapath Fx4/H is a powerful 4K videowall controller designed for creative multi-screen installations. Feed a single UHD source and drive four independently configurable Full HD outputs, with scaling, rotation, cropping, bezel correction and frame-rate conversion all handled in hardware for reliable, low-latency performance. Outputs are genlocked for perfectly synchronised playback, and arbitrary regions can be freely positioned and overlapped within an input canvas up to 8K x 8K.
Connectivity includes 1 x DisplayPort 1.2 and 2 x HDMI 1.4 inputs, plus a DisplayPort 1.2 loop-through. All inputs and outputs support HDCP 1.4. Sync options include BNC tri-level genlock or embedded sync. Control is straightforward via dual Ethernet ports with an internal switch for easy daisy-chaining, or USB, using Datapath’s Wall Designer software for Windows and macOS. Once configured, the unit runs standalone and can display a still image on signal loss. Compact yet robust, it features an internal universal PSU (100–240 V).
Ideal for 2x2 or 1x4 videowalls, portrait signage arrays, overlapping canvases and eye-catching retail or exhibition displays.
Includes
- Datapath Fx4/H unit
- IEC mains cable
