The Lightware MX16x16DVI‑Plus is a robust 16x16 DVI matrix switcher engineered for high‑reliability routing in professional AV environments. Built on Lightware’s Slim architecture, it combines a compact 4U, 7‑inch‑deep chassis with low‑noise active cooling, a universal internal power supply and rugged EtherCON networking for dependable installation in space‑ and noise‑sensitive racks.
It delivers uncompressed, zero‑latency video up to 1920×1200 and 2K‑class resolutions at data rates up to 6.75 Gbps. Advanced EDID management, front‑panel crosspoint control and store/recall of full routing presets speed setup and daily operation. Control is flexible via Ethernet (TCP/IP), RS‑232, an integrated web interface and configuration software, while firmware updates can be applied over the network for straightforward maintenance. A powered DVI 5 V output supports accessories such as fibre adapters, and the matrix can route HDMI 1.3 signals with embedded audio (non‑HDCP) using DVI interfaces.
Ideal for corporate meeting suites, education, live events and control rooms where reliable, fully non‑blocking DVI routing and professional remote management are essential.
Includes
- Lightware MX16x16DVI‑Plus 16x16 DVI Matrix Switcher
