This is a used / pre-loved item, we do our best to uphold the quality of all our used equipment.
VERLINDE ENGINE 1 TONNE in D8 +Double Brake
Motor delivered with a 25 meters galvanized chain
Supplied with chain bag, handles
Attention: Flight solo
Direct voltage by plug: CEE 16A - P17 TRI
Used engine in very good condition
Revised and checked
The LIFTKET is the safest lift motor in the industry. Its double brake, the direct voltage or low voltage option, its limit switches with 2 or 4 internal or external cams, its underload protection system, positioning by encoder, its hooking by rotary hook or directly by an eye … Are just as many options that make the LIFTKET the safest and most versatile motor on the market.
TECHNICAL INFORMATIONS
Charge capacity
10 00 kg (1 ton)
Lifting height (chain length)
20 meters
Lifting speed
4 meters per minute
Number of chain strands
1 strand
Load chain EN 818-7, DAT
black phosphated 7 x 22 mm
Model
?
Mounting position
normal position or inverted hoist
Power supply (connector)
400 V - three phase - 5 Hz (CEE 16/4)
Motor power at 50 Hz
0.75 kW
Mechanism group
1Bm / M3 - FEM / ISO
Starts per hour / max.
150 per hour / 25%
Command type
Direct order
Degree of protection
IP 54
Standard
BGV D8
Color
RAL 9005 matt black
Motor dimensions (lxwxh)
371 mm x 257 mm x 155 mm
Motor weight
27 kg
Lost ribs
288 mm / 370 mm
