This is a used / pre-loved item, we do our best to uphold the quality of all our used equipment.
Sennheiser EM 3732-II SKM 5200-II / MD 5235 (470-638MHz) SETSet consists of :
1x Sennheiser EM 3732-II L, 470 – 638 MHz
2x Sennheiser SKM 5200-II, 470 – 638 MHz with MD 5235 Capsule
Sennheiser EM 3732-II L, 470 – 638 MHz
The EM 3732-II is a true diversity receiver that is characterized by high transmission reliability, exceptional audio quality and simple operation. The frequencies are adjustable in 5 kHz steps. Special features
include the DSP-based HiDyn plus expander and its transformer-balanced audio outputs.
Features :
Receiver principle : True diversity
Frequency range L : 470 – 638 MHz
Switching bandwidth : Up to 184 MHz
Receiving frequencies : 6 frequency banks, each with up to 59 factory-preset channels, 1 frequency bank with up to 60 freely tunable channels (in 5 kHz steps)
Frequency stability : ≤ ±2.5 ppm
Sensitivity : typ. 1.5 μV for 52 dBA rms S/N (with HDP, peak deviation) 15 μV for 115 dBA rms S/N
Adjacent channel rejection/spacing type : 75 dB / ±400 kHz, 80 dB / ±800 kHz
Intermodulation attenuation : ≥ 80 dB
Blocking : ≥ 80 dB
Squelch : 13 steps (0 … 30 µV)
Antenna inputs : 2 BNC sockets (50 Ω)
Daisy chain outputs : 2 BNC sockets (50 Ω)
Gain : 0.5 dB ±0.5 dB (ref. to antenna inputs)
Sennheiser SKM 5200-II BK-L, 470-638 MHz
The next evolution of the SKM 5200 worldclass microphone. Extended switching bandwidth of up to 184 MHz. One fixed, one variable channel bank. Low Intermodulation Mode for higher inference immunity. Very rugged housing.
The SKM 5200-II is the next evolution of the SKM 5200 world class microphone. Robust, reliable and user-friendly, the professional hand-held transmitter is suitable for every conceivable type of recording and transmission situation. The mechanics, electronics and operating concept were designed to meet the highest requirements of live events. This is why, for example, the SKM 5200-II now offers a switching bandwidth of up to 184 MHz. The “HiDyn plus™” noise suppression system developed by Sennheiser reduces RF noise to an absolute minimum, ensuring a wide dynamic range and crystal-clear sound. Programming is extremely flexible: the SKM-II 5200 has both a fixed and a variable channel bank. All parameters are shown on a backlit LCD; they can be locked to prevent accidental adjustment, and checked within seconds. The SKM 5200-II is available in four frequency variants – L, N, N-US and P – as well as in three colors: black, nickel and steel blue (haematite). The hand-held transmitter is compatible with all capsules, battery and rechargeable battery compartments of the 5000 series as well as with Neumann microphone heads.
Features :
Up to 184 MHz switching bandwidth
Low-intermodulation mode (LoI)
Switchable output power
Award-winning design
Audio sensitivity adjustable in steps of 1 dB from -40 to 0 dB
2 AA batteries for at least 7 hrs of operating time
Frequencies adjustable in steps of 5 kHz
Convenient jog dial
Switchable low-cut
Sennheiser MD 5235 Capsule
Cardioid dynamic especially designed for loud stage use, matte black. The capsule design is based on the capsules used in the vocal microphones of the Sennheiser e 900 series. Acoustically optimized for loud stage use, the MD 5235 allows vocalists to cut through high sound levels.
Features :
Rugged sound inlet basket for rough stage use
Shock-mounted capsule minimizes handling noise and vibration
Floating Directivity: The directivity changes from narrow super-cardioid at very high frequencies over cardioid to wide cardioid at very low frequencies. By this means, high-frequency feedback is effectively rejected while the low-end sounds rich and full. Furthermore, the proximity effect is reduced as well as the sensitivity to wind and handling noise.
High feedback rejection
Very good vocal projection
High speech intelligibility
Powerful sound for live vocal performances
Hum compensating coil protects against electromagnetic interference
Very lightweight aluminium voice coil for excellent transient and good treble response
Compatible with SKM 5200 and SKM 5000
