This is a used / pre-loved item, we do our best to uphold the quality of all our used equipment.
YAMAHA PM5D (No RH)DIGITAL CONSOLE MODEL 48 INPUT CHANNELS/24 OUTPUTS
Console delivered with no flight case - 01 x Single power supply without flight case
Equipment in good general condition - Revised
Characteristics:
64 inputs (48 mono + 4 analog stereo, 4 internal stereo returns) Sampling frequency of up to 32 bits / 96 kHz AD & DA converters in linear format at 24 bits Output bus: 24 mix buses (configurable as sub groups or auxiliary sends) .. + 2 stereo outputs (ST A & B or LCR), 8 matrices, 8 mute groups 8 DCA groups (Digitally Controlled Amplifiers, behaving like VCA) The peak-meter bar graphs are integrated into the control surface .. (an additional VU meter is not necessary) 48 balanced XLR-3-31 type inputs for analog audio signals + microphone preamplifiers 4 additional stereo Line inputs 8 high-quality stereo multi-effects modules quality (reverb, delay, modulation effects, etc.) 4-band parametric equalizer (High, High mid, Low mid, Low) Separate noise gate and compressor controls LR, LCR & Surround Pan modes DELAY section on each surround channel, with a range of 0- 10 00 ms 12 EQ graph. 31 bands that can be inserted from any output bus / input channel Very intuitive and comfortable use Channel name display Large color display screen Motorized fader of 10 0 mm for adjusting the input level of the channel MATRIX bus input 1 to 8: parameter matrix grid Supplied with Mac & PC compatible editing software for on-line / off-line control High quality power supply unit (model PW8000, optional) Incl. 3 flexible gooseneck lamps
