This is a used / pre-loved item, we do our best to uphold the quality of all our used equipment.
L-ACOUSTICS LA4 AMPLIFIER LA4 ( R2 )Power: 4 x 800 watts
INTEGRATED AMPLIFIER AND PROCESSOR
Equipment revised and checked
Delivered without flight case
LA4 - Amplified controller
The LA4 amplified controller belongs to the generation of high-end integrated controllers totally dedicated to controlling L-ACOUSTICS ® speaker systems. The LA4 combines in a 2U format the resources of a 2 x 4 DSP driving four amplification channels delivering up to 10 00 watts each, a complete factory preset library, an intuitive user interface, two Ethernet connection ports for driving network, a connection panel for audio inputs and speaker outputs, and a slot for an optional AES / EBU input card.
Complete steering system
• Factory presets for passive and active modes
• Flexible matrixing between the two inputs and the four amplified outputs
32-bit floating point DSP, 96 kHz sampling
• Cascaded 24-bit A / D converters, 130 dB dynamic range
• Combined IIR / FIR algorithms
• Adjustable entry and exit times • Section dedicated to the equalization of systems, controllable from the LA NET WORK • Real-time excursion and temperature control using the L-DRIVE process
• Fixed latency = 3.9 ms (or 3.4 ms with optional AES / EBU card)
4-channel amplification
• Universal switching power supply, 120/230 V
• 4 x 800 W / 8 Ω at 1% of THD, all channels powered (4 x 930 W peak).
• 4 x 10 00 W / 4 Ω at 1% of THD, all channels powered (4 x 1600 W peak).
• Amplification gain = 32 dB.
Audio specifications
• Frequency response: 10 Hz - 30 kHz, -0.1 / + 0.15 dB under 8 Ω
• Output noise level: -73 dBV (20 Hz - 20 kHz, A-weighted)
• Output dynamic range: 111 dB (20 Hz - 20 kHz, A-weighted)
• Maximum input level: +22 dBu (balanced, THD 1%)
• Channel separation:> 80 dB (1 kHz)
• Input impedance: 22 kΩ, balanced
Dimensions
• H x W x D: 88 (2U) x 483 x 420 mm
• Weight (net): 11.1 kg
• Finish: black and anthracite gray
