This is a used / pre-loved item, we do our best to uphold the quality of all our used equipment.
Number of inputsHDC: 1 system
Number of Outputs
HDC: 2 systems
Input/Output Signals
Extension digital signal
HDCP compatible
Input/Output Connectors
RJ-45
Supported formats
VGA to QWXGA
*WUXGA/QWXGA only supports Reduced Blanking
480i/480p/576i/576p/720p/1080i/1080p
Color depth
24 bit, 30 bit, 36 bit Deep Color
Dot Clock
25MHz to 165MHz
TMDS Clock
25MHz to 225MHz
Plug and Play
Supports DDC2B
(choose from built-in EDID, EDID copied from monitor, or EDID of connected receiver)
Digital Audio Input/Output
Multi-channel linear PCM up to 8 channels
Sampling frequency: 32 kHz to 192 kHz, quantization bit rate: 16 bit to 24 bit
function
Contents
Daisy chain connection, I/O signal status display, Anti-storm, RS-232C transmission (I/O connector (RJ-45))
Extension Cable
Suitable Cable
Cat5e UTP/STP, Cat6 UTP/STP, CAT.5E HDC cable
Maximum extension distance
60 m
Other specifications
Power supply voltage
AC ~ 100V - 240V±10%, 50Hz / 60Hz±3Hz
Power Consumption
Approx. 16 W
External dimensions
210(W) x 44(H) x 300(D) mm (EIA half rack 1U, not including protrusions)
mass
1.9 kg
temperature
Operating range: 0°C to +40°C
Storage range: -20°C to +80°C
Humidity
Usage range: 20% to 90% (no condensation)
Storage range: 20% to 90% (no condensation)
accessories
Power cord (1.8 m)
