Excellent used condition (flight case included with 4)
SE38442991
The d&b audiotechnik T10 is an exceptionally versatile, ultra-compact passive 2-way loudspeaker. Its unique design allows it to function flawlessly as either a high-directivity point source speaker or a highly efficient line array element. Featuring a toolless, rotatable horn system, the T10 serves as a flexible, high-performance solution for theaters, corporate events, broadcast studios, and live orchestral shows.
Key Features
Dual-Mode Functionality: Operates as a stand-alone point source or quickly scales into a multiple-cabinet vertical line array.
Toolless Rotatable Waveguide: The high-frequency horn can be mechanically rotated ninety degrees from the outside of the cabinet without removing the grill, allowing instant transition between point source and line source modes.
Acoustic Lens Engineering: An integrated acoustic lens on the front grill expands horizontal dispersion to 105 degrees in line array mode, curving the wavefront to provide a precise 90 x 35-degree pattern when stood upright for point source applications.
Dipolar Driver Arrangement: Features two 6.5-inch low-frequency drivers positioned around a 1.4-inch high-frequency compression driver. This dipolar placement delivers exceptional directivity and dispersion control even at lower frequencies.
Rugged & Lightweight Build: Housed in an impact-resistant polyurethane hard foam enclosure featuring integrated line array rigging hardware, weighing just 11 kilograms.
Specifications
- Configuration: Passive 2-way loudspeaker with rotatable horn
- Components: 2 x 6.5-inch neodymium LF drivers, 1.4-inch exit HF compression driver
- Frequency Response: 68 Hz to 18 kHz
- Max Sound Pressure Level (SPL): Up to 132 dB (depending on amplifier setup and array mode)
- Nominal Impedance: 16 Ohms
- Power Handling: 200 Watts RMS / 800 Watts Peak
- Dimensions: 197 x 470 x 300 mm (7.8 x 18.5 x 11.8 inches)
- Weight: 11 kg (24 lbs)
