This is a used / pre-loved item, we do our best to uphold the quality of all our used equipment.
Used | BSS - Soundweb 9088IIFlightcase: Not included
Accessories: None
The 9088ii Networked Signal Processor forms the heart of the Soundweb system. In a single rack space unit, it offers 8 analogue audio inputs, 8 analogue audio outputs, 200 MIPS of digital signal processing, a pair of network jacks, and a variety of control options.
The front panel of the 9088iis has a number of LEDs to allow a quick view of activity on the audio inputs and on the network. It also has a mini-DIN connector for an RS-232 serial port: this is normally used to connect a PC for system setup and control.
Frequency response (+-0.5dB): 15Hz to 20KHz
THD: <0.01% (20Hz to 0KHz, +10dBu output)
Maximum output level: +20dBu
Inter-channel Crosstalk: <-75dB
Maximum network cable length: 300m/1000ft
Power consumption: <35VA
Mains Volts: 85-270V 50/60Hz
Input Impedance: 10kOhms
Maximum input level: +20dBu (+8dBu with 12dB gain)
Gain range: 0 or 12dB
Input impedance: 3.5kOhms
Maximum input level: +20dBu (with 0dB gain)
Gain range: 0 to 70dB
CMRR: >75dB at 1KHz
Equivalent Input Noise (EIN): <-128dBu typ with 150 Ohms source
Phantom power: 48V nominal
Logic output voltage: 0 or +5V unloaded
Logic output impedance: 440 Ohm
Opto output series impedance: 220 Ohms (isolated)
Control input voltage: 0 to 4.5v
Control input impedance: 4.7kOhms to +5V
Opto Output current: 14mA max
Opto output withstanding voltage (off): 80V max.
