This is a brand new item.
Multi-Layer Hi-Res Mixer and Seamless Switcher (Midra)Inputs: 10 (HDBaseT, HDMI, DVI, 3G-SDI, VGA)
Outputs: 2 (HDBaseT, HDMI) + Video
Audio I/O
Up to 3 Live Layer on Background
Mixer and Matrix Mode
Saphyr – H at a glance:
– Based on the Midra platform
– 2 operating modes: seamless switcher & native matrix
– Heavy-duty design for incredible reliability
– High performance video processing
– HDBaseT inputs and outputs
– Advanced audio management
– User-friendly and intuitive graphic interface
10 seamless inputs, 16 total input plugs:
– 2 x DVI-D up to 2048×1152@60Hz
– 4 x HDMI up to 2048×1152@60Hz
– 2 x Universal Analog up to 2048×1152@60Hz
– 4 x 3G/HD/SD-SDI up to 2K@60Hz
– 4 x HDBaseT up to 2048×1152@60Hz
2 outputs with 2 plugs per output:
– 2 x HDMI up to 2048×1152@60Hz
– 2 x HDBaseT up to 2048×1152@60Hz
– 1 x 3G-SDI up to 2K@60Hz
– 4 x BNC (1 x CVBS, 3 x YPbPR) up to 625/576i
Audio :
– 5-pin MCO connectors: 4 for analog audio inputs and 2 for analog audio outputs
– 4 RCA connectors: 2 for S/PDIF audio inputs and 2 for S/PDIF audio outputs
Input:
– DVI (HDMI) / HDMI / SDI Audio de-embedded
– 4 x Audio stereo Analog (Balanced/Unbalanced)
– 2 x S/PDIF (AES-3id compatible)
Output:
– HDMI / SDI Audio embedded
– 2 x Audio stereo Analog (Balanced/Unbalanced)
– 2 x S/PDIF (AES-3id compatible)
Brand: Analog Way
Condition: New
