This is a used / pre-loved item, we do our best to uphold the quality of all our used equipment.
L-ACOUSTICS SPEAKER A15 FOCUSWST® 2-way passive speaker with constant 10 ° curvature, 144dB
Delivered in a double flight case
Pre-owned equipment in perfect condition
Reviewed and monitored
Detailed descriptions
The A15 Focus loudspeaker is designed for mid-range production applications. This 15 '' passive speaker belonging to the versatile A15 system offers exceptionally simple and flexible deployment, without compromising on performance.
Featuring a narrow 10 ° curvature for tight coverage control, the A15 Focus speaker boasts a sound pressure of 144dB and a maximum throw distance of 45m. Panflex technology allows directivity to be adapted to the geometry of the audience and to obtain a remarkably stable frequency response.
It is possible to combine A15 Focus and A15 Wide in vertical source lines, to hang or to stand. The A15 Focus loudspeaker can also be used individually as a configurable directivity point source in front fill or delay spatial reinforcement applications requiring narrow coverage.
The A15 Focus loudspeaker offers a low frequency contour worthy of a large concert system. In addition, the KS21 bass reinforcement makes it possible to reinforce the contour and widen the bandwidth up to 29 Hz.
Highly modular, the A15 Focus loudspeaker is able to offer live performances in events of various sizes or as a complement to a more powerful L-Acoustics system on the largest stages in the world.
Description: WST® 2-way passive speaker with constant 10 ° curvature, amplified by LA4X / LA8 / LA12X
Usable bandwidth (- 10 dB): 41 Hz - 20 kHz ([A15])
SPL maximum1: 144 dB ([A15])
Nominal directivity
Enclosure: 10 °
Panflex: symmetrical 70 ° / 1 10 ° or asymmetric 90 °
Transducers
LF: 1 × 15 '' speaker with neodymium magnet
HF: 1 × 3 '' diaphragm compression driver, neodymium magnet
Acoustic load
LF: bass-reflex speaker, L-Vents vents
HF: DOSC waveguide, Panflex
Nominal impedance: 8 Ω
Connectors
IN: 1 × speakON 4 points
LINK: 1 × speakON 4 points
Hanging and handling
Flush 2-point hanging system
2 handles, 8 angle stops and 2 floor runners
Safety: 1 M8 insert compatible with DIN580
Cabinetmaking: Top quality Baltic beech and birch plywood
Front face
Steel grid with coating
Acoustically neutral 3D fabric
Hanging elements: High quality steel with anti-corrosion coating
Finish: Dark gray-brown Pantone 426 C
IP55
