This is a used / pre-loved item, we do our best to uphold the quality of all our used equipment.
Raising the bar for screen management, the E2 presentation systems provide superior image quality, exceptional input and output density, great expandability and durability. Supporting native 4K input and output, it was the first screen management system to manage 4K projector blends with refresh rates up to 60Hz with full 4:4:4 color sampling and 12bit processing. A truly versatile system, it offers eight mixable PGM outputs and four scaled Aux Outputs for full show control within a single box. Multiple E2s can be linked together to process extremely large pixel canvases supporting the largest displays available.Video inputs
40 inputs via 8 input cards
Up to 16 x 4K inputs - each input card supports up to 2x 4K@60p
16 x SD/HD/3G/6G/12G connectors
12 x HDMI 2.0 (600 MHz max)
12 x DisplayPort 1.2 (600 MHz max)
Video outputs
Up to 18 output connectors among 4 output cards (Event Master series 2 cards)
{each output card supports up to 2x 4K@60p}
4 x SDI (SD/HD/3G/6G/12G),
13 x HDMI (up to 600 MHz)
1 x DisplayPort(up to 660 MHz)
MVR
:
Up to 6x 4K60p outputs and either 4x HDMI for FHD Multi-viewers (1920x1200 max) OR 1x HDMI for UHD/4K60p Multi-viewer
