COLOR SPOT 1200 AT ROBE

This is a used / pre-loved item, we do our best to uphold the quality of all our used equipment.

LYRE ASSERVIE COLOR SPOT 1200 AT ROBE
Lyre spot 1200 w. MSR 1200 lamp
Used - Revised and checked
In Flight case, with lamps and hooks

SO URC E


Lamp: 1200 W short arc discharge
Base: GY22
Approved model: Philips MSR 1200 SA
Control: Automatic and remote on / off
Ballast: Magnetic


ELECTRICAL SPECIFICATION


Wiring options: 208/230/250 V, 50/60 Hz
Power consumption: 1600 VA at 230 V / 50 Hz


MECHANICAL SPECIFICATION


Height: 619 mm (24.4 ") - head in horizontal position
Width: 536 mm (21.1 ")
Depth: 616 mm (24.3 ")
Weight: 51.5 kg (113.5 lbs)


THERMAL


Maximum ambient temperature (Ta): 40 ° C ( 10 4 ° F)
Maximum surface temperature: 135 ° C (275 ° F)


ROTATING GOBOS


Dichroic glass gobos - outside diameter: 37.3 mm, image diameter: 31.5 mm, thickness: 1.1 mm, max. thickness: 5 mm, high temperature borofloat or better glass, coating: dichroic or enhanced aluminum
Glass gobo - outside diameter: 37.0 mm, thickness: 1.1 mm, max. thickness: 5 mm, high temperature borofloat or better glass


PRISMS AND EFFECTS


Outside diameter: 47 + 0 / -0.3 mm
Thickness: Up to 5 mm in rotating slots (up to 8 mm in the center)


CONTROL AND PROGRAMMING


Protocol: USITT DMX-512, RDM support
Control channels: 24 or 32
3 DMX control modes
Setting & Addressing: ROBE Navigation System (RNS)
Display: Blue / white LCD graphic
Pan / Tilt resolution: 16bit
Gobo indexing: 8 or 16bit
Prism indexing: 8 or 16bit
Dimmer: 8 or 16bit
Movement control: Tracking and vector
Ethernet port: Art-Net protocol, ready for ACN
Data in / out: Locking 3-pin & 5-pin XLR
Stand-alone operation
3-editable programs, each up to 99 steps


ELECTROMECHANICAL EFFECTS


Cyan: 0- 10 0%
Magenta: 0- 10 0%
Yellow: 0- 10 0%
CTO: 0- 10 0%
Color wheel: 6 replaceable ″ SLOT & LOCK ″ colors + open
Gobo wheel 1: 6 rotating, indexable, replaceable ″ SLOT & LOCK ″ dichroic glass gobos + open
Gobo wheel 2: 6 rotating, indexable, replaceable ″ SLOT & LOCK ″ dichroic glass gobos + open
Iris: Motorized, stepless
Effect wheel: 4 rotating, indexable, replaceable ″ SLOT & LOCK ″ prisms and effects + open
Frost effect: Separate, variable
Dimmer / Shutter: Full range dimming and variable strobe effect
Focus: 2 m - infinity
Zoom: 13 ° - 42 °
Pan: 530 °
Tilt: 280 °


RIGGING


Mounting points: 8 pairs of ¼-turn locks
Fastening system: ROBE 's own 2x Omega clamps
Fixing option: Pan / Tilt-lock mechanism


OPTIONAL ACCESSORIES


IR remote control
