This is a used / pre-loved item, we do our best to uphold the quality of all our used equipment.
MARTIN MAC VIPER PERFORMANCEOstram HTI 1000 lamp moving head Lyre from fixed installation.
D
elivered in flight case with omega and power supply
Functional machine
Revised and checked Good condition
The MAC Viper Performance is a full-feature framing fixture that delivers an output and performance never before seen in a fixture this size or one using so little power. Unlike other fixtures in this class, the MAC Viper Performance does not forgo an iris or animation wheel – they are both included along with a framing system and rotating gobos.
26000 Lumens – Excellent light quality with a very flat and uniform field and 6000K color temperature
1:4 zoom – Fast zoom with auto-linked focus
Four shutter blades individually adjust +/- 30° while the entire system rotates +/- 55°. Repeats cues with great precision
FEATURES
26000 Lumens – Excellent light quality with a very flat and uniform field and 6000K color temperature
1:4 zoom – Fast zoom with auto-linked focus
Four shutter blades individually adjust +/- 30° while the entire system rotates +/- 55°. Repeats cues with great precision
Large aperture front lens – The 140 mm front lens exceeds the size of any other fixture in this segment for just the right fat beam look
5 rotating gobos – All glass gobos with only a slight focal separation to the framing system
Animation wheel with continuous bi-directional rotation
CMY – Vibrant color mixing with a superior palette of colors including true reds, rich ambers, primary green and deep blues
7-slot color wheel – Static colors and correction filters for added color choice and bump effects
Linear CTO – Daylight to tungsten CCT control and expansion of the CMY palette
Dimmer and shutter - Combined dimmer/shutter system with intensity effects, instant blackout/open and smooth fades
Iris – Fast and tight iris with adjustable dynamic effects
Strobe – Diverse strobe effects using mechanical or electronic control or in combination
Soft frost – A light frost leaves gobo artwork visible with a beautiful soft edge. Includes a linear focus blurring option
4-facet prism – Real beam separation with rotation and index control for dynamic effects and accurate tiling
SPECIFICATIONS
PHYSICAL
Length:
472 mm (18.6 in.) base
Width:
472 mm (18.6 in.)
Height:
731 mm (28.8 in.) head straight up
Weight: 37.9 kg (83.6 lbs.)
Minimum center-to-center distance in side-by-side installation: 650 mm (25.6 in.)
DYNAMIC EFFECTS
Color mixing: CMY, independently variable 0 - 100%
Color wheel: 7 interchangeable dichroic filters + open, indexing, continuous rotation, random color
Aerial wheel: 5 interchangeable texture/breakup gobos + open, indexing, continuous rotation and shake
Gobo animation: Interchangeable animation wheel, indexing, continuous rotation with variable speed and direction
Iris: 0 - 100%
Framing: Rotatable framing module, +/- 55°, with 4 individually controllable blades
Prism: Interchangeable 4-facet rotating prism
Frost: Variable
Mechanical dimmer/shutter: 0 - 100% continuous dimming, variable & random strobe & pulse effects, instant open & blackout
Color temperature control: CTO, variable 6000 - 3200 K
Dimming options: Choice of four dimming curves
Zoom-focus linking system: 3-zone
Zoom: Motorized
Pan: 540°
Tilt: 268°
Position correction system: Absolute position monitoring
Focus: Range varies with zoom angle, from 2 m / 6 m to infinity (approx.)
CONTROL AND PROGRAMMING
DMX channels: 32/40
16-bit control: Dimming, rotating gobos, zoom, focus, pan and tilt
Setting and addressing: Control panel with backlit graphic display and jog wheel or via DMX
Receiver: Opto-isolated RS-485
DMX compliance: USITT DMX512-A
RDM compliance: ANSI/ESTA E1.20
Firmware update: USB memory device or USB/DMX hardware interface over DMX link
OPTICS
Zoom range: 10-44° (1:4)
Color temperature: 6000 K
Output: 26,000 lumens
PHOTOMETRIC DATA
* All Photometric Data measured in steady state (30 minutes warm-up time) at 25°C ambient.
LAMP
Type: 1000 W short-arc discharge
CRI (Color rendering index): >85
Average lifetime: 750 hours
Socket: PGJX36
Ballast: Electronic
Approved lamps: Osram Lok-it! 1000/PS Brilliant, Osram Lok-it! 1000W/PS VS1, Philips MSR Gold MiniFastFit 1000W
SERVICE UTILITIES
Fixture identification: User-settable fixture ID number
CONSTRUCTION
Housing: UV-resistant fiber-reinforced composite
Color: Black
Reflector: Glass, cold light
Protection rating: IP20
GOBOS
Size: E27 (Size E, max. image diameter 27 mm)
Approved material: Borosilicate 3.3 or better with dichroic or heavy matted aluminum coating (metal gobos not approved)
Outside diameter: 37.5 mm +0/- 0.2 mm (1.5 +0/- 0.01 in.)
Maximum image diameter: 27 mm (1.1 in.)
Maximum thickness: 1.1 mm +/- 0.1 mm (0.1 in. +/- 0.01 in.)
INSTALLATION
Mounting points: Eight quarter-turn locking points
Orientation: Any
Minimum distance to combustible materials: 0.3 m (1.0 ft.)
Minimum distance to illuminated surfaces: 3.4 m (11.2 ft.)
CONNECTIONS
AC power input: Neutrik PowerCon
DMX and RDM data in/out: 5-pin locking XLR
USB memory devices: USB host socket
ELECTRICAL
AC power: 120-240 V AC nominal, 50/60 Hz
Power Consumption
* Measurements made at nominal voltage. Allow for a deviation of +/- 10%.
Typical: full output white, no effects moving, regulated fan speed.
THERMAL
Cooling: Filtered forced air (temperature-regulated, low noise)
Maximum ambient temperature (Ta max.): 40° C (104° F)
Minimum ambient temperature (Ta min.): 5° C (41° F)
Maximum surface temperature, steady state, at 40° C ambient: 150° C (302° F)
Total heat dissipation (calculated, +/- 10% at 120 V, 60 Hz): 4180 BTU/hr
ENVIRONMENTAL
RoHS: Compliant
REACH: Compliant
WEEE: Compliant
Proposition 65: Compliant
Efficacy (max output): 20 lm/w
LWR*: 628 lm/kg (285 lm/lb)
LWR = Lumen-to-Weight Ratio
APPROVALS
EU safety: EN 60598-2-17 (EN 60598-1), EN 62471
EU EMC: EN 55015, EN 55103-1, EN 55103-2, EN 61547
US safety: UL 1573
US EMC: FCC Part 15 Class A
Canadian safety: CSA E598-2-17 (CSA E60598-1)
Canadian EMC: ICES-003 Class A
Australia/NZ: C-TICK N4241
INCLUDED ITEMS
Lamp (installed): P/N 97010346
Two Omega clamp attachment brackets with 1/4-turn fasteners: P/N 91602001
Safety and installation manual: P/N 35000258
RELATED ITEMS
Martin Companion Cable: P/N 91616091
Martin Companion Software Suite (including firmware uploader): Free download from www.martin.com
ACCESSORIES
Power Input Cables: Power input cable 3 x 2.5 mm2, H07RN-F OPEN-POWCON 1.5 m (4.9 ft.): P/N 91611800
Power connectors: Power Connector PowerCON Female : P/N 91611794
T-shaped omega clamp attachment bracket with 1/4-turn fasteners: P/N 91602008
Half-coupler (tube) clamp: P/N 91602005
G-clamp (suspension with yoke vertically downwards only): P/N 91602003
Quick-trigger clamp (suspension with yoke vertically downwards only): P/N 91602007
Omega clamp attachment bracket with 1/4-turn fasteners: P/N 91602001
Safety Cable, SWL 60 kg, BGV C1 / DGUV 17, black: P/N 91604006
Safety Cable, SWL 60 kg, BGV C1 / DGUV 17, silver: P/N 91604007
Flightcase for 2 x MAC Viper: P/N 91510180
SPARE PARTS
Osram HTI 1000/PS Lok-it lamp: P/N 97010346
Air filter, head, MAC Viper (sold in multiples of 12): P/N 20800270
ORDERING INFORMATION
MAC Viper™ Performance in cardboard box: P/N 90233100
MAC Viper™ Performance in double flightcase: P/N 90233110
SHIPPING INFORMATION
In cardboard carton:
Shipping dimensions (LxWxH): 580 x 450 x 870 mm (22.9 x 17.8 x 34.3 in.)
