This is a used / pre-loved item, we do our best to uphold the quality of all our used equipment.
L-ACOUSTICS AMPLIFIER LA8 with AES Card4-channel Amplified Controller of 4 x 1 10 0 w
Year 2014
Sold without flight case
The LA8 amplified controller belongs to the generation of high-end integrated controllers totally dedicated to controlling systems
L-ACOUSTICS ® loudspeakers. The LA8 combines in a 2U format the resources of a 2 x 4 DSP driving four amplification channels delivering
up to 1800 watts each, a comprehensive factory preset library, intuitive user interface, two Ethernet connection ports for
network control, a connection panel for audio inputs and speaker outputs.
L-ACOUSTICS ® LA8 preset library
• K1, K1-SB, KUDO
• KARA, ARCS II
• SB18, SB28
• 115XT HiQ
• Products from previous generations: V-DOSC, dV-DOSC,
Complete steering system
• Factory presets for passive and active modes
• Flexible die-forging between the two inputs and the four outputs
32-bit floating point DSP, 96 kHz sampling
• Cascaded 24-bit A / D converters, 130 dB dynamic range
• Combined IIR / FIR algorithms
• Adjustable entry and exit times • Section dedicated to the equalization of systems, controllable from the LA NET WORK • Real-time excursion and temperature control using the L-DRIVE process
• Fixed latency = 3.9 ms or 3.4 ms with AES / EBU
4-channel amplification
• Universal switching power supply, 120/230 V
• 4 x 1 10 0 W / 8 Ω at 1% THD, all channels powered
(4 x 1300 W peak)
• 4 x 1800 W / 4 or 2.7 Ω at 1% THD, all channels powered
(4 x 2500 W peak)
• Amplification gain = 32 dB
Audio specifications
• Frequency response: 10 Hz - 30 kHz, -1.5 / + 0 dB under 8 Ω
• Output noise level: -67 dBV (20 Hz - 20 kHz, A-weighted)
• Output dynamic range: 10 7 dB (20 Hz - 20 kHz, A-weighted)
• Maximum input level: +22 dBu (balanced, THD 1%)
• Channel separation:> 85 dB (1 kHz)
• Input impedance: 22 kΩ, balanced
• AES / EBU input card: consult the LA-AES3 technical sheet
Dimensions
• H x W x D: 88 (2U) x 483 x 420 mm / 3.5 (2U) x 19 x 16.5 in
• Weight (net): 12.2 kg 26.9 lbs
• Finish: black and anthracite gray
