This is a brand new item.
New goods including the THS 4 talkback/headphone box is a universally usable, fully equipped commentator console for the sports area. It offers both the main and talkback microphone outputs and is equipped with the following switches: mic on/off. Cough (for short -term mute). Talkback (for communication with the director). The talkback output provides a line level signal and is equipped with a trim control. The main microphone output remains active even in the event of a power failure if a dynamic microphone is used. Headphone connections: There are two inputs for headphones that support both symmetrical and asymmetrical compounds. Each entrance has a volume control and assignment switch with which the left and/or right channel can be set for the headphones. The input levels affect both ears evenly. Headphones with impedances of 30 to 600 ohms can be operated with full volume. The THS 4 has main and talkback microphone outputs. A adjusting mic on/off switch connects the signal to the main microphone output. The switch shines red when the microphone output is active. There are two types of capacitor microphone supply available, which enable seamless switching when activating the talkback. A three-stage switch selects either phantom feed or "T" voltage and is sunk to avoid unintentionally switching off. A current cough switch (cough key) molts both the microphone output and the talkback output as long as it is pressed. The current talkback switch leads Audio to the talkback output and at the same time switches the microphone output silently. The speaker's microphone is guided by a preamplifier and a line driver, which transmits the signal to line level for the talkback output. A level controller enables the fine setting of the talkback signal. The talkback switch shines green when it is pressed. Headphone section of the THS 4: The headphone section of the THS 4 has two inputs. Each entrance has a volume control and DIP switch to assign the signal to the left and/or right ear. If an input is assigned to both ears, the level adjustments have an evenly effect on both ears. Input signals can be either symmetrically mono or asymmetrical stereo. A switch on the back chooses the right mode. For the flexible connection, there are both 3-pole XLR and 6. 35 mm TRS sockets. Power supply: The THS 4 is operated via a 12 V AC power supply (model: PS12AC1A), which is included in the scope of delivery. Features: Two line level inputs with individual volume controllers. Input Assign switch to assign inputs to one or both ears. Symmetrical or unimmetric inputs via XLR or 6. 35 mm trs. Passive microphone output for maximum operational safety "on-air". Silent switching of the microphone output. Active talkback output (line level) with level control. Mic on, Cough and Talkback switch for control. Headphone connections: 6. 35 mm TRS or 3. 5 mm mini jack. PS12AC1A power supply included.
